CAL-7677933 Calearo antenna DAB adhesive

Antenna DAB+, internal, self-adhesive, SMB connector

Parameters

• transparent self-adhesive foil
• supply voltage: 12V DC phantom power supply
• cable length: 3m (impedance: 50Ohms, capacity: 101pF / m)
• connector: FAKRA female or SMA 90 ° female (FAKRA-SMB adapter included)
• frequency range: 174 - 240MHZ (band III)
• gain: 4 dB
• polarization: veryical
• current consumption: 35mA max.
• working temperature: -40 to + 95 ° C
• dimensions: 28 x 2.5 x 1.5 cm (L x W x H)
• weight: 60g
• Installation: self-adhesive on the glass from the inside, vertically

For cars

• universal
