Pandora ELITE GSM car alarm

Pandora ELITE is the market leader in car alarms and has been developed for the highest level of vehicle security. The system allows communication via modern interfaces (GSM-4G, GPRS, RF 868 MHz-LoRa and Bluetooth 5.0) to achieve continuous control on the vehicle.

Basic unit

• Integrated 4G LTE / GSM modem
• Integrated 868MHz radio communication module with 2-way remote control (LoRa)
• Integrated 2.4 GHz module with low power Bluetooth 5.0 support.
• Nano SIM card slot
• 3 x CAN BUS
• 2x LIN BUS
• Built-in high-sensitivity GPS/GLONASS module
• Support for the use of the RMD-BM v2 module for the immobilizer clone of the BMW series "E"
• Support for cloning the Mercedes-Benz immobilizer
• iOS and Android mobile control
• Personal PIN code deactivating system
• Hands-free mode for activating/deactivating without using a controller
• Immobilizer and 2 anti-hijack modes (Anti-Hi-Jack 1, Anti-Hi-Jack 2)
• Automatic activation
• Authorization mode using buttons on the steering wheel
• Original immobilizer replacement technology during the remote start
• Coded communication
• Unique 128-bit encryption key
• built-in  3D accelerometer to detect tilt, shock and vehicle motion, with sensitivity adjustable via a mobile application.
• Integrated temperature sensor
• The system has an input for an external back-up battery

Immobilizer control (tag)

• Unique 128-bit encryption key.
• LED indication.
• Service switch on / off button.
• Integrated accelerometer
• CR-2032

Tracked vehicle inputs
The Pandora ELITE car alarm allows you to monitor and evaluate the following zones in the vehicle:

• Individual vehicle doors
• Front hood
• Trunk
• Ignition
• Brake pedal
• 2 zonal disturbance from the shock sensor
• Violation from the motion sensor
• Violation from the tilt sensor
• Low voltage on-board network

System set

• Remote control (Pandora D-043)
• Radio tag 2x (Panora BT-760)
• Leather case for a radio tag
• Owner’s personal card
• External VALET button
• Beeper
• Base unit
• Bluetooth RF module RFM-470
• External GSM antenna
• Relay module RMD-5M
• External temperature sensors
• Wires and fastening kit
• Piezo siren PS-332BT with backup battery
• User manual
• Wiring diagram
• Packaging

Mobile application
